23288RK-H3288-JTEKT
JTEKT

Self aligning roller bearing

23288RK-H3288-JTEKT

410 410 790 790 280 280

Part number : 23288RK-H3288-JTEKT

JTEKT
Trustpilot

Trustpilot

Description

The Self Aligning Roller Bearing, known as 23288RK-H3288-JTEKT JTEKT, has an inner diameter of 410 mm, an outer diameter of 790 mm and a thickness of 280 mm.

See data sheet
N/A

  8 to 10 days

product_sheet product_sheet product_sheet
product_sheet_padlockSecure payment

Need help or advice?

(646).712.9672

Trustpilot

Description

The Self Aligning Roller Bearing, known as 23288RK-H3288-JTEKT JTEKT, has an inner diameter of 410 mm, an outer diameter of 790 mm and a thickness of 280 mm.

See data sheet
product_sheet product_sheet product_sheet
product_sheet_padlockSecure payment

Need help or advice?

(646).712.9672

Trustpilot

TECHNICAL DATA

  • INSIDE DIAMETER
    410  MM
  • INSIDE DIAMETER
    16.142"
  • OUTSIDE DIAMETER
    790  MM
  • OUTSIDE DIAMETER
    31.102"
  • THICKNESS
    280  MM
  • THICKNESS
    11.024"
  • LIMITING SPEED
    300  RPM
  • BRAND
    JTEKT
  • DYNAMIC LOAD
    8580  KN
  • STATIC LOAD
    12300  KN
  • PACKAGING
    1
  • N° EAN13
    3616060792594

Description

The Self Aligning Roller Bearing, known as 23288RK-H3288-JTEKT JTEKT, has an inner diameter of 410 mm, an outer diameter of 790 mm and a thickness of 280 mm.

EXPERT ADVICE



What is a self aligning bearing?


 A spherical bearing, or swinging bearing is a bearing that is able to accept that the spindle is slightly out of alignment.   These bearings are regularly located in grinders or agricultural machines, regularly placed in "cast iron SN" bearings, with a shim washer and seals specific to these bearings.   Attention, there are 2 important variants:   • The cylindrical bore bearing, which will be mounted directly on the shaft, in force
• The tapered bore bearing, mounted with a sleeve, on an axis smaller than the bore of basis of turnover.   The tapered bore is indicated by the letter "K" in the reference.


What does the letter "K" mean in the reference?


 The letter K means that the bearing has a tapered bore. It should therefore almost always be mounted with a conical sleeve. Attention, this bearing is generally mounted on an axis of 5mm less than the dimension indicated for the bearing.
