Self aligning roller bearing 22340RHAK-AH2340-JTEKT

190 190 420 420 138 138

Part number : 22340RHAK-AH2340-JTEKT

JTEKT

Description

The Self Aligning Roller Bearing, known as 22340RHAK-AH2340-JTEKT JTEKT, has an inner diameter of 190 mm, an outer diameter of 420 mm and a thickness of 138 mm.

N/A

  8 to 10 days

product_sheet product_sheet product_sheet
product_sheet_padlockSecure payment

Need help or advice?

(646).712.9672

Description

The Self Aligning Roller Bearing, known as 22340RHAK-AH2340-JTEKT JTEKT, has an inner diameter of 190 mm, an outer diameter of 420 mm and a thickness of 138 mm.

product_sheet product_sheet product_sheet
product_sheet_padlockSecure payment

Need help or advice?

(646).712.9672

TECHNICAL DATA
  • BRAND
  • N° EAN13
    3616060794017
  • INSIDE DIAMETER
    190  MM
  • INSIDE DIAMETER
    7.48"
  • OUTSIDE DIAMETER
    420  MM
  • OUTSIDE DIAMETER
    16.535"
  • THICKNESS
    138  MM
  • THICKNESS
    5.433"
  • LIMITING SPEED
    820  RPM
  • DYNAMIC LOAD
    2570  KN
  • STATIC LOAD
    2920  KN
  • PACKAGING
    1
Description

The Self Aligning Roller Bearing, known as 22340RHAK-AH2340-JTEKT JTEKT, has an inner diameter of 190 mm, an outer diameter of 420 mm and a thickness of 138 mm.

EXPERT ADVICE

What is a self aligning bearing?

A spherical bearing, or swinging bearing is a bearing that is able to accept that the spindle is slightly out of alignment. These bearings are regularly located in grinders or agricultural machines, regularly placed in "cast iron SN" bearings, with a shim washer and seals specific to these bearings. Attention, there are 2 important variants: • The cylindrical bore bearing, which will be mounted directly on the shaft, in force
• The tapered bore bearing, mounted with a sleeve, on an axis smaller than the bore of basis of turnover.
The tapered bore is indicated by the letter "K" in the reference.

What does the letter "K" mean in the reference?

The letter K means that the bearing has a tapered bore. It should therefore almost always be mounted with a conical sleeve. Attention, this bearing is generally mounted on an axis of 5mm less than the dimension indicated for the bearing.
