Self aligning ball bearing 2304-JTEKT

20 20 52 52 21 21

Part number : 2304-JTEKT

JTEKT

Description

The Self Aligning Ball Bearing, known as 2304-JTEKT JTEKT, has an inner diameter of 20 mm, an outer diameter of 52 mm and a thickness of 21 mm.

See data sheet
N/A

  8 to 10 days

product_sheet product_sheet product_sheet
product_sheet_padlockSecure payment

Need help or advice?

(646).712.9672

Description

The Self Aligning Ball Bearing, known as 2304-JTEKT JTEKT, has an inner diameter of 20 mm, an outer diameter of 52 mm and a thickness of 21 mm.

See data sheet
product_sheet product_sheet product_sheet
product_sheet_padlockSecure payment

Need help or advice?

(646).712.9672

TECHNICAL DATA
  • BRAND
  • N° EAN13
    4549250102660
  • INSIDE DIAMETER
    20  MM
  • INSIDE DIAMETER
    0.787"
  • OUTSIDE DIAMETER
    52  MM
  • OUTSIDE DIAMETER
    2.047"
  • THICKNESS
    21  MM
  • THICKNESS
    0.827"
  • LIMITING SPEED
    11000  RPM
  • DYNAMIC LOAD
    18  KN
  • STATIC LOAD
    4.65  KN
  • PACKAGING
    1
Description

The Self Aligning Ball Bearing, known as 2304-JTEKT JTEKT, has an inner diameter of 20 mm, an outer diameter of 52 mm and a thickness of 21 mm.

EXPERT ADVICE

What is a self aligning bearing?

A spherical bearing, or swinging bearing is a bearing that is able to accept that the spindle is slightly out of alignment. These bearings are regularly located in grinders or agricultural machines, regularly placed in "cast iron SN" bearings, with a shim washer and seals specific to these bearings. Attention, there are 2 important variants: • The cylindrical bore bearing, which will be mounted directly on the shaft, in force
• The tapered bore bearing, mounted with a sleeve, on an axis smaller than the bore of basis of turnover.
The tapered bore is indicated by the letter "K" in the reference.

What does the letter "K" mean in the reference?

The letter K means that the bearing has a tapered bore. It should therefore almost always be mounted with a conical sleeve. Attention, this bearing is generally mounted on an axis of 5mm less than the dimension indicated for the bearing.
